CASTING SYSTEMS
PT Cast Casting Machine
This vacuum pressure casting machine for platinum with argon gas-controlled atmosphere delivers an excellent product with a smooth surface finish.
Key Features
-
Vacuum Pressure
-
Melt Up to 500g of Platinum
-
Improved Induction System
-
Interactive Touch-Screen Display
-
Water-Cooling for Temperature Stabilization
SPECIFICATIONS
GENERATOR TYPE
Inverter
DIET
220/400 VAC±10%, 50/60 Hz, 3P + N + PE, 5.5 kW
TYPE OF CASTING PROCESS
Inductive
TYPE OF METAL
Platinum
MAXIMUM METAL QUANITY (g)
500 gr
MAXIMUM CYLINDER DIMENSION
Ø= 130 mm, H= 170 mm
MIN. PRESSURE INERT GAS (ARGON)
1.5 bar
MAXIMUM TEMPERATURE
1900°
WORK CYCLES
up to 6 / hour
COOLING SYSTEM
Forced ventilation and liquid cooling (with external chiller, not included)
DISPLAY
7" touch screen
WEIGHT
400 kg
