Product Specifications
Generator Type
Inverter
Type of Casting Process
Inductive
Maximum Metal Quantity
500 g
Min. Pressure Inert Gas (Argon)
1.5 bar
Work Cycles
Up to 6 / hour
Display
7" touch screen
Power Supply
220/400 VAC ±10%, 50/60 Hz, 3P + N + PE, 5.5 kW
Type of Metal
Platinum
Maximum Cylinder Dimension
Ø = 130 mm, H = 170 mm
Maximum Temperature
1900°
Cooling System
Forced ventilation and liquid cooling (with external chiller, not included)
Weight
400 kg
Product Dimensions
Additional Details
Cooling System: Optional external water cooling system for special order at additional cost
Intuitive Interface touch screen display
Three preset programs for platinum, gold, and silver
Up to 50 customizable programs to adjust parameters such as temperature, duration, and cooling speed
Equipped with Ethernet connectivity for remote monitoring and support
Practical drawer with a refractory stone, ideal for storing crucibles, tongs, and other essential tools
Automatic chamber tilting
What Comes With PT Cast
Casting Kit with crucible, cylinder, and Rubber
Note:
We do not normally stock this item.
This item is Heavy and will result in higher shipping costs.
Out of Stock and Special Order items will ship when available.
